Hydrogen energy compressor of FC150-20, FC110-15

（Product Introduction）
High-speed gas bearing for oil free operation.High power density, benefit from highest speed. Optimized aerodynamic & electromagnetic for highest total efficiency. Integrated temperature measurement for overload protection.
（Core Strengths）
Product characteristics
The highly integrated high-speed electric drive centrifugal compressor adopts high-efficiency and reliable air bearing technology to provide high-quality compressed air for various applications.
（Service advantage）
With the business model of “service +manufacturing+service”, the company provides users with end-to-end complete and full life cycle system solutions, such as system R&D design, fluid machinery product manufacturing, system energy-saving transformation services. The PLC control system developed independently can realize optimal matching between unit energy consumption and system operating condition. Ensure to provide users with efficient, safe and reliable gas compressor products, and provide gas compression station general contracting services, such as EPC, BOT,BOO modes. The company will insist on the road of specialization, and finally achieve the long-term development goal of “ building a century old enterprise and creating a world-class”.
Scope of application
The products are widely used in water treatment facilities, mechanical conveying system(mcs), dehumiditication, drying &fuel desulfurization compositing fermentation, sand blasting, incinerators, oxygen supply, plating bath, back washing, etc.
Technical parameters

compressor parameter model  FC150-20  FC110-15  bearing type   gas bearing mass flow    rated   150-195g/s  110-135g/s pressure ratio rated  2.6-2.8  2.6-2.7 maximum speed  150000rpm  150000rpm inlet temperature  -50-50℃ power  20kw  15kw efficiency ≧78%  ≧76% voltage 200-800VDC communication interface  Can  Can weight  <25kg cooling   liquid cooling start-stop cycle   >100000 times
