50.8 - 130mm Tube Forming Machine For Heat Exchanger Uncoiler

50.8 - 130 MM Tube Forming Machine for steel water pipe Production, galvanzied Tube Making



Tube forming machine specification



1. pipe O.D(round):50.8mm-130mm

2. Wall thickness:2.0-5.0mm

3. length:4-12m

4. Speed:60m/min



Basic necessaries for the BuyerL:

Steel strips	material	Low-carbon steel, low alloy steel:,σs≤345mpa,σb≤610mpa
	I.D	Φ350~Φ450mm
	O.D	Φ600~1000mm
	Width	100~320mm
	Thickness	1.2-4.5mm
	Maximum.weight	≤3500KGS



Accordingly to the market demands. We are given the standard models as blew, and this is for your reference

only, the production range and main technical can be adjustable suppose your company have special requirement.

Tube forming machine Specification
Mill Model	OD range (mm)	Thickness range(mm)	Line Speed(m/min)
ZY-16	7.6-16	0.3-1.0	120
ZY-20	10-25.4	0.3-1.5	120
ZY-32	12.7-38.1	0.6-1.8	120
ZY-45	16-50.8	0.7-2.0	110
ZY-50	20-63.5	0.8-3.0	90
ZY-60	25.4-76.2	1.0-3.2	80
ZY-76	31.8-88.9	1.2-3.75	80
ZY-89	33.4-101.6	1.2-4.5	75
ZY-125	50.8-130	2.0-5.0	60
ZY-165	76.2-168	2.0-6.0	50
ZY-219	88.9-219	2.0-8.0	50
ZY-273	89-273	3.0-12.0	40
ZY-325	89-325	3.0-12.7	40
ZY-406	114-406	4.0-16.0	40
ZY-508	219-508	4.0-19.1	40
ZY-610	273-610	4.0-19.1	40
ZY-660	273-660	4.0-22	40



Brief of tube making machine application:



Tube forming machine as known of steel tube manufacturing line, using the high frequency welder and rollers to produce all kinds of steel tube, profile, etc. also widely used in construction tubes, precision tubes, auto tubes, fence, heat exchanger, furniture tube, pressure tube production, with suitable finishing equipment, machine also can capable to produce the API pipe, gas transportation, and high standard tubes and so on.



Company Advantage



Steel Tube production is an industry which need qualified machine and experienced technology link together to produce the products, that means the machine and experience are both important, our company are only tube making machine manufacture whom use self-machine to produce steel tubes in large quantity, we are improving our machine with running them to get experienced technology.



Choose us, you are not only get the machine from us, you are also get he experienced technology from us.





Tube forming machine production process:



According to different customer, the machinery consist by different process, but our company having the standard production process as blew, this is for your reference, suppose your company have special requirement, we could discuss and make your special design.

Uncoiler→ Shear&welding machine→ Accumulator (Cage) →Forming machine→ HF welding→ Sizing machine→ Flying saw (Cold saw) → Run out table

Type Of Welding:	High Frequency Welding	Application:	Construction,furniture, Oil And Gas Transportation
Type Of Forming:	Forming By Rollers	Feature:	High Speed, High Precision
Special Requirement:	Can Be Design As Per Customer Requirement
