Gas turbine agent brand: Capstone vericor

（Product Introduction）
Ultra-low emissions,Accepts renewable fuels with up to 5000 ppm H2S content, One moving part-minimal maintenance and downtime,Patented air bearing-no lubricating oil or coolant, 5 and 9 years Factory Protection Plans available.
（Core Strengths）
Remote monitoring and diagnostic capabilities;Integrated utility synchronization and protection;Small, modular design allows for easy, low-cost installation; Proven technology with tens of millions of run hours and counting;
Electrical power output can be up to 1mw by integrating the C200.
（Service advantage）
Various types of steam turbines can be designed and manufactured according to specific parameters. With the business model of “service +manufacturing+service”, the company provides users with end-to-end complete and full life cycle system solutions, such as system R&D design, fluid machinery product manufacturing, system energy-saving transformation services. The company will insist on the road of specialization, and finally achieve the long-term development goal of “ building a century old enterprise and creating a world-class”.
scope of application
Digester gas, landfill gas, straw degradation, junked tire degradation,emergency power supply and CHP.
Capstone Technical Parameters

Model	power	efficiency	Exhaust gas temperature	Exhaust gas flow	Weight	dimensions	Sound		Emission standard
C30	30kw	26%	275℃	0.31kg/s	405kg	0.76*1.5*1.8m	65dBA		Low emission
C65	65kw	29%	309℃	0.49kg/s	758kg	0.76*1.9*1.9m	65dBA		Low emission
C20  0	200kw	33%	280℃	1.3kg/s	2776kg	1.7*3.8*2.5m	65dBA		Low emission
C600	600kw	33%	280℃	4.0kg/s	14200kg	3*9.1*2.9m	65dBA		Low emission
C800	800kw	33%	280℃	5.3kg/s	15600kg	3.0*9.1*2.9m	65dBA		Low emission
C1000	1000kw	33%	280℃	6.7kg/s	17000kg	3.0*9.1*2.9m	65dBA		达标 Low emission
VPS3	3086kw	26.8%	602℃	12.7kg/s	34000kg	2.64*7.72*6.1m	90dBA	Low emission
VPS4	3451kw	28.4%	582℃	12.7kg/s	34000kg	2.64*7.72*6.1m	90dBA	Low emission
